Light-weight, streamlined clamp generally used in small diameter applications such as air & fuel lines,300 stainless steel hex screw,lightweight, low profile, compact design allows ease of installation in restricted applications. the 9mm band width generates significant sealing pressure with relatively low installation torque levels.
300 stainless steel mini hose clamps are used to fasten hoses and tubes to fittings and pipes. The only tool needed is a screwdriver or hex driver. Size is based on clamp diameter range and may also be specified as an SAE size. Standard series clamps meet or exceed SAE torque specifications, have 9mm slotted hex head screws.
All stainless steel types offer good corrosion resistance. To determine the size needed, install the fitting, measure the outside diameter of the hose and choose a clamp that will accept that size in about the middle of its range.
applications: for marine, agricultural, industrial and automotive uses. corrosion resistance varies with stainless components.
● Band width: 9mm
● Band thickness:0.7mm
● Hex. head screw: 7mm Hex head
● Under RoHS & REACH standard
W1 : All in carbon steel with zinc plated
W4: All in SS300
Available in bulk packaging, pack of 10, blister card packaging, polybag packaging, tag packaging, and customer designed packaging.
