Recommended tightening torque 11.9 Nm (106 lb in).
Hose Clamps Hi-Torque All in SS316 for applications that require extra high levels of tightening torque.
They can be used on hose applications such as spiral wound wire reinforced suction hose.
Hose Clamps Hi-Torque All in SS316 are suitable for heavy duty applications with plastic or reinforced hoses.
Hose Clamps Hi-Torque All in SS316 forces make this clip suitable for heavy duty applications where stubborn leakage.
● Band width: 1/2” (12.7mm) ,9/16”(14.2mm),5/8”(15.8mm)
● Band thickness: 0.024” (0.6mm)
● Hex. head screw: 5/16” (7.9mm)
● SAE J1508 type F Standard
● Under RoHS & REACH standard
● The recommended installation torque is 7.0 Nm (62 in-lbs).
1. Quadra-Lock construction provides high torque
2. Material,logo stamped on the clamps
3. Size stamped on the band
W1 : All in carbon steel with zinc plated
W2: Band and housing in stainless steel SS300, bolt in carbon steel with zinc plated
W4: All in SS300
W5: All in SS316
Available in bulk packaging, pack of 10, blister card packaging, polybag packaging, tag packaging, and customer designed packaging.
